Product > LTE/5G Router > IPR400 > IPR-400 (LTE Routers )
- Standard LTE Routers capable of terminal configurations without environmental restrictions
- Provide a Web UI for network settings
- Easy to use various settings on the router
- Wired & Wireless Fail-Over
- Support for redundancy with a variety of network configurations
- Configuring a secure network enhanced with SSL VPN support
- SSL VPN Cilent load
제품 규격
| Item | Details |
|---|---|
| Product Name | IPR-400 |
| Chipset | LTE : Qualcomm MDM9607, AP : Mediatek MT7620A |
| Communication Standard | LTE Release 9, Category 4 |
| Supported Speed | LTE : D/L : 150Mbps, U/L : 50Mbps |
| Band | FDD-LTE : Band 1/5/7 |
| RF Sensitivity | Tx Pwr : 23dBm Rx Sen : -93dBm ※ All SPECs comply with the 3GPP |
| Antenna | LTE : 2dBi Dipole external antenna |
| Memory | Serial Flash 16MB | DDR2 64MB |
| Interface | • 4-10/100 Ethernet RJ45 (1-WAN/LAN, 3-LAN) • 8-LED (WAN, PWR, LAN(3), INT, WiFi, LTE) • 2-LTE Antenna (SMA Type) • 1-USIM • 1-Reset Switch |
| Function | • 4G LTE/Ethernet Mode • DMZ/Super DMZ/Auto Super DMZ • Wired and Wireless Duplexing • WEB UI • Static IP, DHCP Client • SSL VPN Client • MAC/IP/Port Filtering • FOTA Firmware Upgrade • Port Forwarding • NMS Remote Management • Wi-Fi 802.11 b/g/n Support *optional* |
| Operation Temperature | -25℃~70℃(95% Humidity) |
| Power Supply | DC 12V 1A |
| Size | 142mm × 98mm × 20mm |
다운로드
-
IPR-400 Catalog
